The best all-round canopy on the market.

All Jumping Styles (Slider Up/Down)
All Experience Levels

2080€ +VAT

OSP2 Design FEATURES

  • Class-leading deep brake performance
  • 3D shaped ZP leading edge
  • MDV5 as standard (5 bottom skin vents)
  • SLAT leading edge system
  • New bridle attachment point
  • Lighter tail pocket design
  • Continuous brake lines
  • Spectra insert brake settings
  • Bottom skin mini ribs
  • Additional canopy sizes
  • Tailgate
  • White Dacron lines
  • Control and centre cell lines in red colour
  • Large mesh slider
  • F111 fabric construction

Available Sizes

185 205 225 235 245 255 265 275 285 305

OSP2 OPTIONS

  • Black Dacron lines (with red or white tailgate lines)
  • PN9 lightweight fabric construction
  • Soft links
  • 'Black edition' label, reinforcement tapes, thread and slider in black
  • Fine mesh slider or slow slider
  • Spectra lines (only for slider up use)

A decade of OSP1 Feedback

The OSP1, originally released in 2007 redefined the BASE canopy market with numerous revolutionary features to improve the opening and flight characteristics - known for its reliable fast openings, precise control, unparalleled deep brake handling and powerful flare. Now it is time for an update incorporating the latest design innovations, the OSP2.

OSP2 is an all-round BASE canopy that brings joy to slider up and excels for slider down. (slow slider recommended for terminal jumps).

Improved Glide

We have refreshed the design retaining all the great features of the original OSP whilst improving the performance envelope.

The OSP2 has a similar horizontal speed as the original OSP and improved glide.
As standard the OSP2 retains the MDV5 , ZP leading edge with SLATS and mini stabilizers from the OSP1.

 Better Performance

The ZP leading edge design has been improved using the same split panel technique as seen on the Vision, reducing the sink rate and increasing performance.

The bridle attachment point is moved further back, so that the tension from the PC is applied to all the lines during opening, instead of just the AB lines, this improves the behavior of the deploying canopy and helps reduce the chance of tension knots.

Fine Tuning

The tail pocket design has been improved to reduce weight. The brake lines are now continuous without loops at the cascades and this also helps reduce the risk of tension knots.

The brake settings are now made from Spectra insert loops to improve durability, helping the lower brake lines to last longer.

We have added 3 additional sizes 235, 255 and 275 as many pilots found themselves exactly between 2 sizes.

OSP2 canopy can be ordered in either F111 or PN9 lightweight material. As standard, the OSP2 is equipped with white, or at extra cost, black Dacron lines. Center tail gate and brake lines are made in red colour. We also offer the »Black option« where all reinforcement tapes and thread are in black colour as well as the OSP2 logo on the outer rib. As standard the canopy is equipped with rapid links or optional soft links.

MDV - Mono Directional Valve

Atair has always been at the cutting edge of parachute design and technology, as demonstrated with the introduction of numerous innovations such as the Mono Directional Valve (MDV) technology. MDV is a unique design that allows the air to flow into the canopy via bottom skin vents during the deployment stage and also during deep brake descent. In normal flight, the vents stay closed and do not disturb the internal airflow inside the canopy.

A canopy with MDV offers additional performance by increasing the canopy flight envelope in deep brakes, before reaching the stall. The canopy still has a great flare when equipped with MDV. When making a jump with the slider up, the canopy will inflate a bit faster than normal, but the true benefits of MDV technology are fully exploited on slider down jumps. The Atair MDV system also has a very low packing volume. During deployment, MDV technology provides superior canopy pressurization, reducing the amount of altitude required for canopy inflation and allowing the jumper almost immediate control of the canopy.

SLAT System

The SLAT system is used to increase the maximum lift coefficient and reduce stall speed. Slats are small leading edge airfoil extensions that are forming a slot at the first 10% of the leading edge. Part of the air that is entering the cell is directed through the slot back to the upper side of the canopy, speeding up the airflow and resulting in delayed separation of the airflow, allowing the canopy to maintain lift at lower speeds and a higher angle of attack before reaching the stall, and also reducing vertical speed. The SLATs are applied to the leading edge of cells #3, #4 and #5, because on rectangular platform wings, the stall occurs first at the middle of the span, i.e. on the center cells.

The SLAT system provides:

● Reduction of canopy forward speed during the opening stage, allowing more time to correct your heading with the risers during low altitude jumps in close proximity to the objects.

Improved deep brakes flight, with crisp toggle response and reduced canopy inertia during steep approaches, enabling easy and accurate, on the spot landings in constricted areas.

Atair was the first manufacturer to introduce this technology on BASE canopies in 2007.
